  • Face to Face Television

    Description

    Development of an specific System able to capture and process the new TV Standard HbbTV (hybrid TV), where you may receive the information though broadcast and thought internet.

    The user interface is based on the basic remote controls from each TV, developing a System complete usable and intuitive.

    Expertise areas

    HbbTV
    H.264 video compression
    Ethernet
    GUI (user interface)
    Partners:

  • Videoconference System

    Description

    Stand alone box for video-conferencing using standard TV. The system allows video-conferencing through ADSL and TV. Friendly user interface and easy to use thanks to Open GL capabilities.

    Thanks to OMAP3530 capabilities, we are able to encode/decode video H.264 VGA (or 720p) and audio AAC encoding/decoding and AEC simultaneously.

    Expertise areas

    Based on TI's OMAP architecture
    Multi-processor architecture design ( ARM + DSP + open GL 2.0)
    DR, NAND Flash and Compact Flash I/II memories SD/MMC card
    10/100 BaseT Ethernet
    WiFI
    PAL/NTSC composite video output
    HDMI
    Microphone and speaker
    H.264, MPEG4 video compression
    AAC, AES audio compression
    IR receiver
    4 USB 2.0 HOST
    Conventional and fine pitch BGA

  • Samba DVB-H

    Description

    SAMBA challenge consists of the development of an advanced real time monitoring system of end-user experience on DVB-H applications. Its aims to support the development of DVB-H market, as well as information society.

    SAMBA uses the cutting edge technologies to provide a unique solution for DVB-H market.

    Expertise areas

    Based on TI's DM642 DSP
    Transport Stream demuxer
    DVB-H Api
    10/100 BaseT Ethernet
    Video server
    Rf diversity receiver
    Remote management through TCP/IP

  • Metrology System based on Computer Vision

    Description

    IP camera customized for a metrology application in production lines. Through the use of 4 cameras, the profile of the desired product is inspected and validated or discarded based on whether it conforms to the quality parameters set by the manufacturer.

    The analysis of the profiles is done in real time as they are outputted from the production line. Thanks to its Ethernet connection, the cameras send all the information to a server to be stored on a database, giving a total control over the production. Due to the application and sector this camera is designed to be used in, the resolution in the measurements approaches the microns.

    The camera is capable of doing all the processing with images of 6.6 Mpixels. An external monitor can be attached to it to show the result of each inspection and statistics of the current process. Special care has been taken to ease the integration with existing automated systems. Thus, it incorporates a wide spectrum of interfaces and inputs/outputs.

    Expertise areas

    Based on TI's DM642 DSP
    Integrated programming software via web server
    FPGA (Xilinx)
    6.6 Mpixels CMOS sensor
    10/100 BaseT Ethernet
    Opto-isolated inputs/outputs
    RS-232, RS485
    Upgradable firmware via web
